4x AIM120 lock systems



Cover for canon - re-engineering



Electrical wiring system

The compressor with SBAC is isolated from all electrical wiring.

Add.....



Refuelling valves



Final setup - Jeti System

Central Box 310
Central Box 100
REX7 Assist
REX7
RSat900
RCSW

Battery holder



Bateries and equipment - pre version



AIR systems for gear and doors

I need to change the setup. I’m removing the Xicoy door sequencer; it doesn’t work well with the Jettronics HF valve. I’ll configure it differently. I’ll add a Jeti CentralBox 100 to get more servo outputs and use the Jeti sequencer to handle the landing gear and door operation. I’ll also need to add a Jeti MBar for air pressure telemetry data.

Pylons ready



Personal camuflage

I'll make a small change to stand out.

M61 Vulcan



M61 Vulcan - ammunition



Wing connectors

TE D-3100D (12pin)

Air layout - final



Final Canon Vulcan M61 - ABS Resin 0,05mm



M61 Vulcan - final data 3Dprint



Next steps - desk for air equipment's



... for checking the UAT´s

AIR scheme

Cabin Open & Close

The cabin is moved by a linear servo. I still have to check the opening angle with the original and adjust it if necessary. The opening lock is on two small servo motors.

Electronics layout - basic placement

Radio equipment + Unilight lighting including BEC + 2x UAT. I will place the compressed air control under the cabin. that will be the next step.

New power scheme for F15XXL

I want to avoid problems with the compressor. I will separate the entire RC assembly from the compressor. I will not control the compressor via a channel, but it will be set to autonomous operation. I will collect telemetry data about the pressure in the system via the XICOY door sequencer.
